CNPG Recipe 26 - Extension image catalogs

CloudNativePG lets the ClusterImageCatalog carry extension images alongside the operand, a capability every currently supported release already has, so a Cluster manifest only needs to name an extension and nothing else. This recipe deploys the community’s extension catalog and shows the operator resolving pgvector’s image, paths and dependencies from a single, versioned source of truth per PostgreSQL major version. More importantly, it is the piece of infrastructure that turns extension distribution into a real ecosystem: once an extension lands in the catalog, every Cluster that references it inherits it for free, with no manifest ever needing to change again.

In Recipe 22 I introduced the officially maintained ClusterImageCatalog resources that decouple a Cluster’s operand image from a hardcoded tag. In Recipe 23 I showed how the Kubernetes ImageVolume feature and PostgreSQL 18’s extension_control_path let CloudNativePG mount pgvector and PostGIS from separate, dedicated images, referenced explicitly through image.reference inside the Cluster’s postgresql.extensions stanza. And in a follow-up about contributing pg_crash to the postgres-extensions-containers project, I flagged that CloudNativePG 1.29 was about to fold extension images directly into image catalogs.

That feature has shipped. This recipe closes the loop: I deploy the community’s extension catalog, reference it from a Cluster, and watch postgresql.extensions collapse from an explicit image reference to a bare extension name, with the operator resolving everything else from the catalog entry matching the Cluster’s PostgreSQL major version.

Prerequisites #

This builds directly on Recipe 23, so the baseline requirements carry over, with one meaningful change since December: ImageVolume is now generally available and enabled by default on Kubernetes 1.35 and later. If you are still on 1.33 or 1.34 you need the feature gate; anything older is out of scope.

• Kubernetes 1.35 or later (or 1.33/1.34 with the ImageVolume feature gate enabled).
• A container runtime with ImageVolume support: containerd 2.1.0+ or CRI-O 1.31+.
• CloudNativePG. Extensions in image catalogs landed in 1.29 and are present in every release the project currently supports (1.29 and 1.30 as of this writing), so any supported CloudNativePG install already has it.
• PostgreSQL 18, for extension_control_path.

If your organisation is still on an older PostgreSQL major and needs this mechanism sooner, the community does not provide extension_control_path or extension image catalogs below PostgreSQL 18. (Note: at EDB we do, and we can provide extension images for our versions of Postgres 15 and later as part of our enterprise offering, for organisations that cannot wait for a major upgrade to get there.)

Kind cluster setup #

For the sandbox itself, follow Recipe 1: grab the latest Kind release, which ships a node image with ImageVolume already enabled by default, so no feature gate is needed here, unlike in Recipe 23. Install the latest stable CloudNativePG following the official instructions.

Deploying the community extension catalog #

Recipe 22 covered installing the community’s official operand catalogs. Today’s addition is a companion kustomize target that patches extensions into the same catalogs:

kubectl apply -k \
  https://github.com/cloudnative-pg/artifacts/image-catalogs-extensions?ref=main

This overlays the base image-catalogs resources with a patch that adds an extensions array to the relevant major entries of the Debian Trixie and Bookworm minimal catalogs. Confirm it landed:

kubectl get clusterimagecatalogs.postgresql.cnpg.io

Then inspect one directly:

kubectl describe clusterimagecatalogs.postgresql.cnpg.io \
  postgresql-minimal-trixie

Trimmed to a couple of representative entries (digests shortened, other extensions and majors snipped):

apiVersion: postgresql.cnpg.io/v1
kind: ClusterImageCatalog
metadata:
  name: postgresql-minimal-trixie
spec:
  images:
    # majors 13 through 17 omitted: no extensions array yet
    - major: 18
      image: ghcr.io/cloudnative-pg/postgresql:18.4-...-minimal-trixie@sha256:...
      extensions:
        - name: pgvector
          image:
            reference: ghcr.io/cloudnative-pg/pgvector:0.8.6-...-18-trixie@sha256:...
        - name: postgis
          image:
            reference: ghcr.io/cloudnative-pg/postgis-extension:3.6.4-...-18-trixie@sha256:...
          ld_library_path:
            - system
          env:
            - name: GDAL_DATA
              value: ${image_root}/share/gdal
            - name: PROJ_DATA
              value: ${image_root}/share/proj
        # ... <snip> pg-crash, pg-ivm, pgaudit, timescaledb-oss, wal2json

Only the PostgreSQL 18 entry carries an extensions array today. Earlier majors in the same catalog have none, since extension_control_path is a PostgreSQL 18 feature and extension image catalogs only make sense for the major versions that support it. The mechanism itself is not tied to 18: the moment PostgreSQL 19 ships, extending this same catalog to carry a 19 entry with its own extensions array is a matter of building that major, not of inventing new machinery. Note too that PostGIS keeps its ld_library_path and env overrides bundled into the catalog entry itself, so you inherit the correct GDAL and PROJ paths without repeating them in every Cluster.

The manifest: cluster and database #

Here is Recipe 23’s cluster, for comparison, once pgvector is added directly:

postgresql:
  extensions:
  - name: pgvector
    image:
      reference: ghcr.io/cloudnative-pg/pgvector:0.8.1-18-trixie

And here is today’s version, using the catalog instead:

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: pgvector
spec:

  imageCatalogRef:
    apiGroup: postgresql.cnpg.io
    kind: ClusterImageCatalog
    name: postgresql-minimal-trixie
    major: 18

  instances: 3

  storage:
    size: 1Gi

  postgresql:
    extensions:
      - name: pgvector

The image.reference block is gone. imageCatalogRef already pins the Cluster to postgresql-minimal-trixie at major: 18, so postgresql.extensions only needs to opt in by name; the operator resolves pgvector’s image, ld_library_path, extension_control_path and dynamic_library_path from the matching catalog entry. If you need a different build for one cluster, say a newer pgvector you are evaluating early, you can still override any of those fields locally: catalog values are defaults, not a lock-in.

Extension activation in the database is unchanged from Recipe 23:

apiVersion: postgresql.cnpg.io/v1
kind: Database
metadata:
  name: pgvector-app
spec:
  name: app
  owner: app
  cluster:
    name: pgvector
  extensions:
  - name: vector
    version: '0.8.6'

Verification #

Confirm the extension binaries were mounted, exactly as in Recipe 23:

kubectl exec -ti pgvector-1 -c postgres -- ls /extensions/

Confirm the extension is active in the app database:

kubectl cnpg psql pgvector -- app -c '\dx'

The interesting new check is the Cluster’s resolved status, which shows exactly what the operator pulled from the catalog:

kubectl get cluster pgvector \
  -o jsonpath='{.status.pgDataImageInfo}' | jq

The output confirms the effective image reference for both the operand and pgvector, resolved from the catalog entry rather than typed anywhere in the Cluster spec:

{
  "image": "ghcr.io/cloudnative-pg/postgresql:18.4-...-minimal-trixie@sha256:...",
  "majorVersion": 18,
  "extensions": [
    {
      "name": "pgvector",
      "image": {
        "reference": "ghcr.io/cloudnative-pg/pgvector:0.8.6-...-18-trixie@sha256:..."
      }
    }
  ]
}

Why this matters architecturally #

Recipe 23 already decoupled the PostgreSQL core from extension binaries. What it did not decouple was the Cluster manifest from the exact tag or digest of every extension it uses, and that coupling scales badly: every extension bump or PostgreSQL major upgrade meant editing every Cluster that used it. Folding extensions into the catalog fixes that by extending the separation of concerns Recipe 22 already established for the operand. I expect this to become the recommended way of managing images in CloudNativePG going forward, for the operand and for extensions alike, with direct imageName references and explicit image.reference entries becoming the exception rather than the default:

• Single source of truth per major. The catalog pins the operand and its compatible extension builds together, so you never end up with a pgvector image built for a different PostgreSQL major, OS or CPU architecture than the Cluster it is mounted into. That kind of ABI mismatch is exactly the class of bug image catalogs exist to prevent.
• Separation of concerns, enforced. The platform or maintainer team owns the catalog and its digests; the application team owns the Cluster and simply opts in by name. Neither has to touch the other’s object to do its job.
• Fleet-wide rollout, for extensions too. Bumping the catalog already triggers a rolling update across every Cluster referencing it, and Recipe 22’s spread upgrades (CLUSTERS_ROLLOUT_DELAY) throttle that rollout fleet-wide. An extension patch shipped through the catalog now gets the same safe, staggered rollout as an operand patch, instead of being a manual, cluster-by-cluster edit.
• A clean upgrade path across majors. Moving a Cluster from major 17 to 18, or from one minimal catalog to the next, only ever means changing imageCatalogRef.major. The extensions available at that major are whatever the catalog says they are, which is a much easier invariant to reason about than auditing every image.reference by hand.
• A template, not a mandate. The community catalog is a ClusterImageCatalog like any other, so nothing stops an organisation from forking it, pinning its own extension builds and digests, and maintaining a private catalog that mirrors the same shape. This is exactly the mechanism air-gapped deployments need: mirror the images into your own registry, adjust the image.reference entries, and the Cluster manifests using imageCatalogRef do not change at all.

Conclusion: the catalog is the platform #

This is the “streamlined future” I pointed to at the end of the extensions contributions post: CloudNativePG 1.29 shipping support for extensions in image catalogs, which had been tracked in PR #9781 at the time. Seven extensions ship through the community catalog today: pg-crash, pg-ivm, pgaudit, pgvector, postgis, timescaledb-oss and wal2json. That list is not fixed. Every extension that lands in postgres-extensions-containers through the contribution guide I walked through with pg_crash is a candidate for the next catalog update, and once it lands there, it reaches every Cluster referencing the catalog without a single manifest changing.

That is the part I find most significant about this recipe. Extension contribution, extension distribution and extension consumption used to be three separate concerns, each with its own manual step. They are now three stages of the same pipeline: contribute the image, patch the catalog, name the extension. If you maintain an extension the community relies on, or want to, the catalog is where your work actually reaches users, with no downstream manifest ever needing to know it happened.

I have deliberately left one thing untested here: what actually happens when the catalog bumps pgvector to a newer version and a running Cluster has to follow. I will cover updating an extension through the catalog, end to end, in a future recipe.
