CNPG Recipe 23 - Managing extensions with ImageVolume in CloudNativePG

·7 mins
Postgresql Kubernetes Cloudnativepg Pgvector Postgis Imagevolume Declarative Extensions Immutability Postgres18 Operator Database Cnpg Dok Extension_control_path
Table of Contents

Say goodbye to the old way of distributing Postgres extensions as part of the main pre-built operand image. Leveraging the Kubernetes ImageVolume feature, CloudNativePG now allows you to mount extensions like pgvector and PostGIS from separate, dedicated images. This new declarative method completely decouples the PostgreSQL core from the extension binaries, enabling dynamic addition, easier evaluation, and simplified updates without ever having to build or manage monolithic custom container images.

In a previous post, I made the case for the immutable future of PostgreSQL extensions on Kubernetes. Traditionally, achieving immutability meant building large, custom container images for the Postgres operand with every extension needed.

Before the method I am about to show you, the common approach for extensions like pgvector was to use the standard CNPG image, which already came pre-packaged with only a few extensions—a method I detailed in my article on getting started with pgvector on Kubernetes.

Now, I want to show you a groundbreaking, more flexible approach that I believe represents the true future of extension management: a moment that marks the beginning of the end of a multi-year vision we’ve had at EDB and, previously, at 2ndQuadrant.

This new flexibility is unlocked by the latest crucial steps: the combination of PostgreSQL 18’s extension_control_path GUC (Grand Unified Configuration variable) and the Kubernetes ImageVolume feature. We’re leveraging this with CloudNativePG to mount extensions from dedicated container images. Notably, pgvector and PostGIS are the first set of extension images officially released by the community through the postgres-extensions-containers project.

This allows us to use the small, official minimal PostgreSQL images while seamlessly integrating complex extensions like pgvector and PostGIS.

Prerequisites: PostgreSQL 18 and Kubernetes’ ImageVolume #

Before diving into the manifests, I must stress the technical requirements for this approach. It relies on Kubernetes’ capability to expose an entire container image as a volume, which CNPG then mounts into the PostgreSQL pod.

This functionality requires Kubernetes 1.33 or later because it depends on the ImageVolume feature. This feature is not yet enabled by default, but it is expected to be generally available and enabled by default in Kubernetes 1.35 (available this month, December 2025).

If you are using Kind for your local development environment, you must explicitly enable this feature gate when creating your cluster, like in the example below:

(cat << EOF
kind: Cluster
apiVersion: kind.x-k8s.io/v1alpha4
featureGates:
  ImageVolume: true
EOF
) | kind create cluster --config -

For our demonstration, I will be using PostgreSQL 18. Note that to run these manifests, you must also have the latest stable version of CloudNativePG installed in your Kubernetes cluster; instructions can be found in the official CloudNativePG documentation.

Starting with the minimal CNPG cluster #

I always recommend starting simple. We begin with the most basic, lightweight CNPG Cluster definition. I am using the official CNPG minimal image for PostgreSQL (which I have written about previously in my piece on leveraging the new CNPG supply chain and image catalogs) for PostgreSQL 18 (which you can learn more about running PostgreSQL 18 today on Kubernetes).

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: angus
spec:
  # the small, official `minimal` CNPG base image for Postgres 18
  imageName: ghcr.io/cloudnative-pg/postgresql:18-minimal-trixie
  instances: 1

  storage:
    size: 1Gi

This cluster is perfectly ready to serve basic PostgreSQL operations. This image adheres to the minimal design principle: at just 260MB, it contains only the core database binaries, serving as a clean, dependency-free foundation for our immutable extension strategy. However, if you attempt to run CREATE EXTENSION vector; right now, the command will fail because the required extension control and shared object (.so) files are not present in the minimal base image.

Introducing pgvector via a dedicated image #

Instead of switching to a heavy, custom imageName, I introduce the new postgresql.extensions block. This is where the magic happens. I am instructing CloudNativePG to find a separate image (which, for pgvector, weighs only 613KB) containing the compiled pgvector binaries and mount it into the PostgreSQL container using ImageVolume.

The manifest #

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: angus
spec:
  imageName: ghcr.io/cloudnative-pg/postgresql:18-minimal-trixie
  instances: 1

  storage:
    size: 1Gi

  postgresql:
    extensions:
    - name: pgvector
      image:
        reference: ghcr.io/cloudnative-pg/pgvector:0.8.1-18-trixie
---
apiVersion: postgresql.cnpg.io/v1
kind: Database
metadata:
  name: angus-app
spec:
  name: app
  owner: app
  cluster:
    name: angus
  extensions:
  - name: vector
    version: '0.8.1'

Verification: the extension is ready #

Once you apply the manifests above, CloudNativePG handles both mounting the binary files via ImageVolume and running the necessary CREATE EXTENSION SQL.

First, let’s confirm the pgvector binaries have been successfully mounted into the pod’s filesystem. I’m targeting the primary pod (assuming the name follows the pattern angus-1) and listing the contents of the mounted /extensions/ directory:

kubectl exec -ti angus-1 -c postgres -- ls /extensions/

The output confirms the extension directory is present, mounted from the separate extension image:

pgvector

Next, we verify that the extension is active and ready in the app database:

kubectl cnpg psql angus -- app -c '\dx'

The output confirms the declarative process was successful:

                                      List of installed extensions
  Name   | Version | Default version |   Schema   |                  Description
---------+---------+-----------------+------------+------------------------------------------------------
 plpgsql | 1.0     | 1.0             | pg_catalog | PL/pgSQL procedural language
 vector  | 0.8.1   | 0.8.1           | public     | vector data type and ivfflat and hnsw access methods
(2 rows)

What I have achieved here #

  1. Cluster.spec.postgresql.extensions: I have registered the pgvector extension by referencing a specific extension image. This image holds only the compiled binaries for pgvector.

  2. ImageVolume in action: CloudNativePG intelligently mounts the contents of ghcr.io/cloudnative-pg/pgvector:0.8.1-18-trixie directly into the PostgreSQL pod’s file system, ensuring the necessary binaries are available and read-only. Underneath, this is achieved by leveraging the extension_control_path GUC, a key feature introduced in PostgreSQL 18, which allows the database to locate the necessary extension control files outside of the traditional installation directories.

  3. Database.spec.extensions: This resource handles the final, declarative activation. I instruct PostgreSQL to run CREATE EXTENSION vector VERSION '0.8.1';. This is key: CloudNativePG manages this command declaratively, meaning I never have to connect and run SQL myself. Furthermore, the version field is crucial; by simply applying a new image and changing this value, CNPG orchestrates the PostgreSQL update path (provided the extension itself supports the upgrade).

This cleanly decouples the PostgreSQL core from the extension binaries, providing immutability without the custom image maintenance headache.

Scaling up: integrating multiple complex extensions #

The real power of this method becomes apparent when dealing with complex, interdependent extensions like PostGIS. PostGIS requires several companion extensions and shared library dependencies, which are notoriously difficult to manage manually.

I can easily add PostGIS by simply listing it under extensions. Note the inclusion of the ld_library_path configuration for PostGIS; this is a vital element that ensures its dynamic linker paths are correctly configured for maximum reliability. Finally, I define all the necessary PostGIS-related companion extensions in the Database resource:

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: angus
spec:
  imageName: ghcr.io/cloudnative-pg/postgresql:18-minimal-trixie
  instances: 1

  storage:
    size: 1Gi

  postgresql:
    extensions:
    - name: pgvector
      image:
        reference: ghcr.io/cloudnative-pg/pgvector:0.8.1-18-trixie
    - name: postgis
      image:
        reference: ghcr.io/cloudnative-pg/postgis-extension:3.6.1-18-trixie
      ld_library_path:
      - system
---
apiVersion: postgresql.cnpg.io/v1
kind: Database
metadata:
  name: angus-app
spec:
  name: app
  owner: app
  cluster:
    name: angus
  extensions:
  - name: vector
    version: '0.8.1'
  - name: postgis
    version: '3.6.1'
  - name: postgis_raster
  - name: postgis_sfcgal
  - name: fuzzystrmatch
  - name: address_standardizer
  - name: address_standardizer_data_us
  - name: postgis_tiger_geocoder
  - name: postgis_topology

After applying this full manifest, I encourage you to check the validation commands from the previous section again. You’ll find that the /extensions/ directory now contains both pgvector and the PostGIS files, and the \dx output confirms that all PostGIS dependencies, including postgis_topology, have been successfully created in the database.

Summary #

The ability to mount extensions from separate images using ImageVolume with CloudNativePG 1.27+ is a game-changer. It allows us to:

  • Decouple: upgrade the core PostgreSQL image independently of the extension images. This also applies to the build project (which is very important for us maintainers and contributors of CloudNativePG).
  • Dynamic and easy evaluation: extensions can be added dynamically to an existing cluster, making the evaluation of new features fast and frictionless.
  • Maintain small images: my base imageName remains small, secure, and simple.
  • Ensure consistency: CloudNativePG handles all the complex volume mounting and dependency mapping, guaranteeing a consistent, immutable environment across the entire cluster without needing custom Dockerfile builds.

Finally, I want to mention that we are currently working to standardise the way we create these extension images in the postgres-extensions-containers repository on GitHub.

The goal of this project (see issue #15) is to scale up the number of supported extensions by providing a framework that can be used by more contributors to add extensions they like, as long as they become component owners/maintainers for that extension in the CloudNativePG community. I will cover our progress on this project in a future post.

Stay tuned for the upcoming recipes! For the latest updates, consider subscribing to my LinkedIn and Twitter channels.
