CNPG Recipe 21 – Finer Control of Postgres Clusters with Liveness Probes

In this article, I explore how CloudNativePG 1.27 enhances PostgreSQL liveness probes, including primary isolation checks that mitigate split-brain scenarios and integrate seamlessly with Kubernetes. We also discuss how these improvements lay the groundwork for advanced features like quorum-based failover while maintaining stability, safety, and community-driven decision-making.

In the previous articles — CNPG Recipe 19 - Finer Control Over Postgres Startup with Probes and CNPG Recipe 20 - Finer Control of Postgres Clusters with Readiness Probes — I covered the enhancements to the probing infrastructure introduced in CloudNativePG 1.26, focusing on startup and readiness probes respectively.

In this article, I’ll explore the third — and last — probe provided by CloudNativePG: the liveness probe.

Understanding Liveness Probes #

Liveness probes have been part of Kubernetes since the very beginning. Their purpose is to ensure that a workload — in our case, PostgreSQL — is still running and able to perform its intended function.

Just like the readiness probe, the liveness probe only starts running after the startup probe has succeeded. It then continues to run periodically for the entire lifetime of the container.

As mentioned in CNPG Recipe 19, liveness probes share the same configuration parameters as startup and readiness probes:

• failureThreshold
• periodSeconds
• successThreshold
• timeoutSeconds

How CloudNativePG Implements Liveness Probes #

At a high level, the goal of the liveness probe is to confirm that the PostgreSQL workload is healthy. As long as the probe succeeds, the Kubernetes kubelet will keep the pod running. If the probe fails, the kubelet will restart the pod.

From CloudNativePG’s perspective, the liveness probe checks whether the instance manager is functioning. If you’re not familiar with it, the instance manager is the entrypoint (PID 1) of the postgres container — the main workload. I often describe it as a distributed extension of the operator’s brain, or more playfully, its right arm.

The instance manager provides, among other things, a REST API used by the operator to coordinate operations. This includes controlling the PostgreSQL server process itself and serving the endpoints for the startup, readiness, and liveness probes.

By default, the liveness probe reports success as long as the instance manager is up and running. It reports failure if it cannot be reached for more than .spec.livenessProbeTimeout seconds (default: 30 seconds).

Starting with CloudNativePG 1.27, this basic check is enhanced on the primary instance with an additional safeguard: it now verifies whether the instance is isolated from both the API server and the other replicas. I’ll cover the details of this improvement later in the article.

The .spec.livenessProbeTimeout setting acts as a higher-level abstraction over the raw Kubernetes probe configuration. Internally, it maps to the following parameters:

failureThreshold: FAILURE_THRESHOLD
periodSeconds: 10
successThreshold: 1
timeoutSeconds: 5

Here, FAILURE_THRESHOLD is automatically calculated as:

FAILURE_THRESHOLD = livenessProbeTimeout / periodSeconds

This means that with the default values (livenessProbeTimeout: 30, periodSeconds: 10), FAILURE_THRESHOLD will be 3.

Full Probe Customisation #

Just like with readiness probes, if your scenario requires finer control, you can customise the liveness probe through the .spec.probes.liveness stanza by defining the standard Kubernetes probe parameters you should already be familiar with.

The following example configures Kubernetes to:

• Probe the container every 5 seconds (periodSeconds)
• Allow up to 6 consecutive failures (failureThreshold) — still equivalent to a 30-second tolerance window, but with a higher probing frequency — before marking the container as not alive

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: freddie
spec:
  instances: 3

  storage:
    size: 1Gi

  probes:
    liveness:
      periodSeconds: 5
      failureThreshold: 6

Liveness Probe and Primary Isolation #

A few months ago, an issue was raised in CloudNativePG regarding the risk of a split-brain scenario during a network partition. This sparked a productive discussion within the community, which I recommend reading. It ultimately led to a new default behaviour introduced in CloudNativePG 1.27, after debuting as an experimental feature in 1.26.

The enhancement applies specifically to the liveness probe on primary pods. In addition to checking that the instance manager is running, the probe now also verifies that the primary can:

• Reach the Kubernetes API server
• Reach the instance manager of every replica, via their REST API endpoint

If either check fails for longer than the configured livenessProbeTimeout, the kubelet restarts the pod. On restart, the instance manager first attempts to download the Cluster definition. If this fails — for example, because the pod is still isolated — PostgreSQL will not start. This ensures that an isolated primary cannot continue accepting writes, reducing the risk of data divergence.

While this does not completely prevent split-brain — the isolated primary can still accept writes from workloads in the same partition until the pod is terminated — it helps mitigate the risk by shortening the time window during which two primaries might be active in the cluster (by default, 30 seconds).

This behaviour is conceptually similar to the failsafe mode in Patroni. The key difference is that CloudNativePG provides its own built-in mechanism, fully integrated with the Kubernetes liveness probe.

As mentioned earlier, the primary isolation check is enabled by default on every PostgreSQL cluster you deploy. While there is generally no reason to disable it, you can turn it off if needed, as shown in the example below:

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: freddie
spec:
  instances: 3

  storage:
    size: 1Gi

  probes:
    liveness:
      isolationCheck:
        enabled: false

Key Takeaways #

CloudNativePG’s probing infrastructure has matured into a robust, Kubernetes-native system that now accounts for both replicas and primaries. The primary isolation check in the liveness probe enhances cluster reliability by reducing the risk of unsafe operations in network-partitioned scenarios, making PostgreSQL behaviour more predictable and safer for administrators.

Key practical takeaways:

• Primary isolation check enabled by default: Liveness probes now verify that a primary can reach the API server and other replicas.
• Mitigates split-brain scenarios: Reduces the time window during which multiple primaries could accept writes. When synchronous replication is used (as recommended), the likelihood of a split-brain on an isolated primary is close to zero.
• Fully integrated with Kubernetes probes: Achieves robust behaviour without introducing external dependencies.
• Foundation for quorum-based failover: Enables the experimental quorum-based failover feature in 1.27, which will be stable in 1.28, offering safer synchronous replication failover.

This evolution reflects a careful, staged approach: first reorganising startup and readiness probes, then adding primary isolation checks, and finally paving the way for advanced failover mechanisms—demonstrating CloudNativePG’s commitment to stability, safety, and innovation, and ensuring that the project and its community were mature enough to make these decisions together.

Stay tuned for the upcoming recipes! For the latest updates, consider subscribing to my LinkedIn and Twitter channels.
