CNPG Recipe 18 - Getting Started with pgvector on Kubernetes Using CloudNativePG

Learn how to set up a PostgreSQL cluster with the pgvector extension on Kubernetes using CloudNativePG—all in a fully declarative way. This article walks you through the process in just a few minutes, from cluster creation to extension installation.

pgvector has quickly become one of the most popular PostgreSQL extensions, especially in the context of AI and machine learning. It introduces native support for vector data types, which are essential for similarity search, embedding storage, and other AI-driven use cases.

In this article, I’ll walk you through how to create a PostgreSQL cluster with pgvector support in Kubernetes using CloudNativePG. As always, we’ll take a fully declarative approach—and it’ll only take a few minutes.

Prerequisites #

Before you begin, make sure you have a local Kubernetes environment up and running using Kind and that you’ve installed the latest version of CloudNativePG. If you haven’t yet, follow the steps in “CloudNativePG Recipe 1 - Setting up your local playground in minutes” to get everything ready.

Step 1: Define the PostgreSQL Cluster #

Let’s start by creating a simple, single-instance PostgreSQL cluster named pgvector. You can scale it later depending on your needs.

Create a file named pgvector.yaml with the following contents:

apiVersion: postgresql.cnpg.io/v1
kind: Cluster
metadata:
  name: pgvector
spec:
  instances: 1

  storage:
    size: 1Gi

Then apply it with:

kubectl apply -f pgvector.yaml

Step 2: Check Cluster Status #

Once the cluster is being created, you can monitor its status with the cnpg plugin:

kubectl cnpg status pgvector

Step 3: Install the pgvector Extension #

By default, CloudNativePG creates a database and a user both named app for applications (see “CNPG Recipe 2 - Inspecting Default Resources in a CloudNativePG Cluster” for more information). CloudNativePG also supports a powerful feature: you can declaratively define a Database resource and specify extensions to be installed in it.

Since pgvector is already bundled in the default operand container image for PostgreSQL, installing it is straightforward. Create a new file named pgvector-db.yaml with the following contents:

apiVersion: postgresql.cnpg.io/v1
kind: Database
metadata:
  name: pgvector-app
spec:
  name: app
  owner: app
  cluster:
    name: pgvector
  extensions:
  - name: vector

Apply it with:

kubectl apply -f pgvector-db.yaml

You can inspect the new Database resource using:

kubectl get database pgvector-app

or:

kubectl describe database pgvector-app

The controller for the Database resource transparently manages CREATE EXTENSION, as well as related commands like ALTER EXTENSION and DROP EXTENSION, when the resource is modified or deleted.

Step 4: Verify the Extension #

Let’s now connect to the app database and confirm that the vector extension is installed:

kubectl cnpg psql pgvector -- app -c '\dx'

You should see output similar to this:

                            List of installed extensions
  Name   | Version |   Schema   |                     Description
---------+---------+------------+------------------------------------------------------
 plpgsql | 1.0     | pg_catalog | PL/pgSQL procedural language
 vector  | 0.8.0   | public     | vector data type and ivfflat and hnsw access methods
(2 rows)

You’re All Set #

And there you have it—pgvector is installed and ready to use in your app database, running inside a PostgreSQL cluster managed by CloudNativePG on Kubernetes. What you build with it is entirely up to you. If you’re just getting started and want to experiment, head over to the project’s “Getting Started” guide for some practical examples.

This setup offers a solid foundation for experimenting with vector-based AI workloads using Postgres in a cloud-native way.

Stay tuned for the upcoming recipes! For the latest updates, consider subscribing to my LinkedIn and Twitter channels.
